Replacement Lamp - Multilab Tekindo Pratama

Easily replicate different viewing environments with a choice of lamp options. Ensure perception of colour will be consistent across the Point-of-Sale locations. VeriVide lamp options for viewing booths cover all supply chain viewing conditions. Select the right lamp options for your VeriVide light booth to comply with brand specification.

Colour perception differs when colour is viewed under different light sources.

Often, colours need to be assessed using more than one light source in order to replicate different viewing environments. If only one light source is used for colour assessment, metamerism can easily slip through the net with the potential to cause problems at the consumer interface.

When two or more materials match visually under one light source but mismatch under another, the inconsistency is termed metamerism. It is most usually caused by differences in the colouring matter used for each material. To detect metameric matches, you need to assess and match the colour submissions alongside the standards under different light sources.

CIE Daylight Illuminants

Light Source	Name	Lamp Description	C.R.I.	Length	Watts	Diam	Product Code
D75	VeriVide D75 "Artificial Daylight"	Correlated colour temperature 7500K. Conforming to the USA ASTM (American Society for Testing and Materials) D1729-82 standard for D75 Illuminant. With high CIE specifications, for accurate colour matching.	96	600mm	20w	T12	600D75
D65	VeriVide D65 "Artificial Daylight"	VeriVide D65 “Artificial Daylight”. Correlated colour temperature 6500K. Within the tolerances prescribed in BS 950: Part 1; and all international specifications for D65 illluminant. Specified for most applications where there is a need to maintain colour consistency and quality. Conforming highly to the CIE specifications, for accurate colour matching.	98	600mm 1200mm 1500mm	18w 36w 58w	T8 T8 T8	600D65 1200D65 1500D65
D50	D50 "Artificial Daylight"	Correlated colour temperature of 5000K. For the Graphic Technology and Photography industries. D50 lamps conform to BS 950: Part 2 and ISO 3664. Recommended for transmitted light source to view transparencies and for the reflected light source to view reproductions.	98	600mm 1200mm 1500mm	18w 36w 58w	T8 T8 T8	60050 120050 150050

CIE Illuminant 'A'

Light Source	Name	Lamp Description	C.R.I.	Length	Watts	Diam	Product Code
'F'	Tungsten Filament	Tungsten Filament Lighting. Approximate colour temperature of 2800K. Required by BS 950: Part 1 as a test for metamerism (approximating CIE Illuminant ‘A’). Typical light source used within domestic environments.	100	Globe Globe Round Clear-284mm Opal-284mm	40w 60w 150w 60w 60w	45mm 45mm - - -	40G450 60G450 150FILO 28460CL 28460OP
	Tungsten Halogen	Tungsten Halogen Lighting (CIE Illuminant ‘A’). This represents incandescent A (inc-A) with a colour temperature of 2856K. Typical light source used within domestic environments. Used to check for metamerism.	100	-	35w	-	HALO/12V /35WLP

Alternative (fluorescent) lighting / Point of Sale

Light Source	Name	Lamp Description	C.R.I.	Length	Watts	Diam	Product Code
840 P15	VeriVide 840P15	Narrow Band Triphosphor Fluorescent Lamps. Correlated colour temperature of 4000K. CIE Illuminant F11. Often chosen as a European “Point of Sale” light source, with good colour rendering and manufactured to a tighter tolerance specification as prescribed by Marks & Spencer. (Formerly TL84P15).	85	600mm 1200mm 1500mm	40w 60w 150w 60w 60w	18w 36w 58w	60084P15 120084P15 150084P15
CWF	Cool White	Cool White Broad Band Fluorescent Lamps. Correlated colour temperature of 4000K. Used as an American “Point of Sale” light source. Moderate colour rendering.	62	600mm 1200mm 1500mm	20w 40w 65/80w	T12 T12 T12	60033 120033 150033
U35	Ultralume 35	Ultralume Narrow Band Triphosphor Fluorescent Lamp.Correlated colour temperature 3500K. An American “Point of Sale” light source, with good colour rendering.	86	600mm 1200mm	17w 32w	T8 T8 T8	600U35 1200U35
830	830	Narrow Band Triphosphor Fluorescent Lamp. Correlated colour temperature 3000K. Often chosen as a European “Point of Sale” light source with good colour rendering. (Formerly TL83).	85	600mm 1200mm 1500mm	18w 36w 58w	T8 T8 T8	60083 120083 150083

Horizon

Light Source	Name	Lamp Description	C.R.I.	Length	Watts	Diam	Product Code
'H'	Horizon Lighting	Colour temperature 2300K. Used for Automotive, Apparel and Metamerism Testing. As specified by the ASTM (American Society for testing and Materials) D1729-74, Standard Practise for Visual Evaluation of Colour Differences of Opaque Materials.	98	-	75w	-	HALO/12V /75W

Ultraviolet

Light Source	Name	Lamp Description	C.R.I.	Length	Watts	Diam	Product Code
UV	Ultraviolet	Ultraviolet Blacklight. Used to detect the presence of Optical Brightening Agents and/or Fluorescent dyes. It is useful when assessing white and Fluorescent shades to check the level present and its evenness.	N/A	Clear-450mm Blacklight-600mm	15w 18w	T8 T8	450UV15 600UV18

CIE Daylight Illuminants	Dimensions (mm), 600(W), 600(H), 600(D)
CIE Illuminant 'A'	Dimensions (mm), 284(W), 284(H), 284(D)
